Ajax Baseline BulletCam HL

Name: Ajax Baseline BulletCam HL
Brand: Ajax
SKU: FDS007/245
Price: 163.632 GBP
Availability: InStock

Code: FDS007/245

from

£136.36

EX VAT

Code: FDS007/245

Resolution Colour

Available in 5 MP and 8 MP resolution options
Choice of black or white finish
Fixed 2.8 mm f/1.6 lens with 100–110° horizontal viewing angle

Have a question about this? Click here

Overview Features Technical Data Downloads & Resources

The Ajax Baseline BulletCam HL is a wired AI-powered IP security camera designed for indoor and outdoor video surveillance.

Available in 5 MP and 8 MP resolutions, with a choice of black or white finishes, it combines detailed video monitoring with hybrid illumination, intelligent object detection and flexible wired connectivity.

A fixed 2.8 mm f/1.6 lens provides a wide horizontal field of view of 100–110°, helping cover larger areas with a single camera. Hybrid illumination combines IR and white LEDs with a range of up to 50 m.

Intelligent lighting control automatically adjusts LED intensity according to conditions, helping prevent overexposure when objects are close to the camera while maintaining visibility at greater distances.

True WDR with a 120 dB dynamic range helps retain detail in scenes containing both bright and dark areas. Integrated AI video analytics can distinguish between people, pets and vehicles, while software-based motion detection provides additional event detection.

A built-in microphone can also record audio when the appropriate settings are enabled.

The BulletCam HL supports PoE 802.3at/af or a 12 V DC supply, providing flexibility when planning an installation. Local recording is supported through microSD cards up to 256 GB, while H.265 and H.264 video codecs are available for video encoding.

An IP65 and IK08 rated enclosure provides protection for demanding indoor and outdoor environments. Integration features include Ajax's encrypted JetSparrow video protocol, configurable visual verification scenarios and ONVIF Profile G and S conformity.

Available in 5 MP and 8 MP resolution options
Choice of black or white finish
Fixed 2.8 mm f/1.6 lens with 100–110° horizontal viewing angle
Hybrid IR and white LED illumination up to 50 m
120 dB True WDR for challenging lighting conditions
AI detection of people, pets and vehicles
Built-in microphone for configurable audio recording
Supports microSD storage up to 256 GB
PoE 802.3at/af or 12 V DC power
IP65 and IK08 rated enclosure

Specification	Details
Model	BulletCam HL (5 Mp/2.8 mm) / BulletCam HL (8 Mp/2.8 mm)
Resolution Options	5 MP / 8 MP
Image Sensor	5 MP: 1/2.8" CMOS; 8 MP: 1/2.7" CMOS
Lens Focal Length	2.8 mm
Maximum Aperture	f/1.6
Lens Iris Type	Fixed
Lens Focal Type	Fixed
Horizontal Field Of View	100–110°
Vertical Field Of View	50–60°
Diagonal Field Of View	125–135°
DORI Distance, 5 MP	Detection: 65 m; Observation: 26 m; Recognition: 13 m; Identification: 6.5 m
DORI Distance, 8 MP	Detection: 90 m; Observation: 36 m; Recognition: 18 m; Identification: 9 m
White LED Illumination	Up to 50 m
IR LED Illumination	Up to 50 m
Minimum Illumination	Colour: 0.005 lx; B/W: 0 lx
Signal-To-Noise Ratio	More than 52 dB
5 MP Video Resolutions	2880 × 1620; 2560 × 1440; 2304 × 1296; 1920 × 1080; 1024 × 576
8 MP Video Resolutions	3840 × 2160; 3072 × 1728; 2592 × 1944; 2944 × 1656; 2880 × 1620; 2560 × 1440; 2304 × 1296; 1920 × 1080; 1024 × 576
Frame Rate	5 MP: up to 25 fps; 8 MP: up to 20 fps
Image Rotation	0°, 180°
Video Codec	H.265, H.264
Dynamic Range	120 dB (True WDR)
Storage	microSD up to 256 GB, Class V30 or faster
Built-In Microphone	Yes
Audio Codec	G711-ULAW, G711-ALAW, G726, G722
AI Object Detection	People, pets, vehicles
Network Port	1 × RJ-45 self-adaptive Ethernet (10/100 Mbps)
Protocols	HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, DHCP, DNS
ONVIF	Conformant with ONVIF Profile G and S
Video Protocol	JetSparrow
PoE Standard	802.3at/af
PoE Power Consumption	5 MP: max. up to 7.3 W, average up to 6.0 W; 8 MP: max. up to 8.1 W, average up to 7.0 W
Power Supply	12 V DC ±20%, 1 A
12 V DC Power Consumption	5 MP: max. up to 6.3 W, average up to 5.1 W; 8 MP: max. up to 7.0 W, average up to 6.0 W
Dimensions	198 × 76 × 76 mm / 7.78″ × 2.99″ × 2.99″
Weight	550 g / 1.21 lb
Operating Temperature	−30°C to +60°C / −22°F to 140°F
Operating Humidity	Up to 90%
Protection Class	IP65, IK08
Colour Options	Black, White
Warranty	24 months

5MP Datasheet	Click here to download
8MP Datasheet	Click here to download
