Global Fire 3I/O-PLUS-1CH Addressable Interface 1 Channel (2 & 3 Channel versions available)

Name: Global Fire 3I/O-PLUS-1CH Addressable Interface 1 Channel (2 & 3 Channel versions available)
Brand: Global-fire
Availability: InStock

Code: FDS202/117

Call to place order

INC VAT

Code: FDS202/117

Fast Activation Response
Loop Powered
Status LEDs for each I/O and O/P

Have a question about this? Click here

Overview Features Technical Data

The 3 I/O PLUS Modules are fully monitored, loop-powered devices designed to interface third-party equipment with a fire alarm control panel using normally open, dry contact connections. Each module supports up to three inputs and three outputs, with every input continuously monitored for fault conditions (open or short circuit) as well as alarm activation.

These modules enable integration of external systems into the fire alarm system, such as sprinkler flow switches to indicate sprinkler activation or extinguishing agent level monitoring in gas suppression systems. Each unit includes a loop short-circuit isolator and up to three voltage-free, single-pole changeover relay outputs, all powered directly from the detection loop without the need for an external 24 V DC power supply.

Relay status is indicated by an onboard red LED, while an 8-way DIL switch allows easy address configuration within the range of 1 to 125. Programmable features include input activation mode selection, delayed input alarm activation, and delayed output activation.

Fast Activation Response
Loop Powered
Status LEDs for each I/O and O/P
Low Power Consumption
Module features an integral short-circuit loop isolator

SUPPLY VOLTAGE	Loop Powered 20V to 30V DC
LOOP CURRENT – QUIESCENT	1.4 mA (1 ch.) – 1.5 mA (2 ch.) – 1.6 mA (3 ch.)
LOOP CURRENT – ALARM / SHORT-CIRCUIT	IQ+ 1.2 mA for each I/P in alarm / IQ+ 1.4 mA max.
LOOP CURRENT – OPEN CIRCUIT	IQ+ 1.0 mA max.
LOOP CURRENT – OUTPUT ACTIVE	IQ+ 1.1 mA for each O/P activated
OUTPUT RELAY CONTACT RATING	2A 30V DC / 0.5A 125V AC
CABLE SIZE	0.5-2.5 mm²
OPERATING TEMPERATURE	-10ºC to +50ºC
HUMIDITY / PROTECTION	Max. 95% no condensation
DIMENSIONS	150 (W) x 90 (L) x 32 (H) mm
WEIGHT	216 g inc. packaging
