Apollo REACH Wireless Addressable Fire Alarm Builder with Advanced Panel

Name: Apollo REACH Wireless Addressable Fire Alarm Builder with Advanced Panel
Brand: Advanced-electronics
Price: 1413.78 GBP
Availability: InStock

Code: FDS550/662

£1,413.78

INC VAT

Code: FDS550/662

Build your wireless fire alarm kit
Apollo REACH compatible

Add these extras to your kit

Please Select

Apollo RW1700-030APO | REACH Wireless Loop Interface Module - XP95(£252.24 inc vat)

Apollo RW1900-901APO | REACH Wireless Manual Call Point(£150.78 inc vat)

Apollo RW1000-600APO | REACH Wireless Optical Smoke Detector(£156.42 inc vat)

Apollo RW1000-400APO | REACH Wireless Heat Detector(£156.42 inc vat)

Apollo RW1000-700APO | REACH Wireless Multi-Sensor Detector(£177.54 inc vat)

Apollo RW1300-110APO | REACH Wireless Sounder Base(£169.08 inc vat)

Apollo RW1300-211APO | REACH Wireless Sounder VAD Base - Red Flash(£250.80 inc vat)

Apollo RW1500-120APO | REACH Wireless Open-Area Wall Sounder - Red Body(£188.82 inc vat)

Apollo RW1500-220APO | REACH Wireless Open-Area Wall Sounder VAD - Red Body & White Flash(£250.80 inc vat)

Have a question about this? Click here

Overview Features Technical Data Downloads & Resources

Build a high-performance addressable fire alarm system using the Apollo REACH Wireless Fire Alarm System Builder, featuring the Advanced Electronics Mx-5101 panel.

This 1-loop addressable panel is equipped with a dedicated Apollo Reach loop card, allowing integration with Apollo’s REACH wireless detection devices.

Ideal for retrofits, complex installations, or locations where cabling is restricted, this system combines the trusted reliability of Advanced Electronics with the flexibility of wireless communication.

Use the builder to customise your system layout and select the right Apollo REACH devices for your project.

Advanced Mx-5101 1-loop addressable panel
Apollo Reach loop card included for wireless compatibility
Supports fully addressable wireless detection and sounders
Expandable and configurable for site-specific requirements
Ideal for heritage sites, schools, commercial buildings and temporary structures

Base Technology	Dual flash-based processors with real-time clock, trace diagnostics, programmable languages and character sets
Display	White backlit 240 x 64 graphical LCD
LED Indicators	22 red (1 x Fire, 1 x More Alarms, 20 x Zonal Programmable), 1 green (Power), 13 amber and 12 bi-colour (Fault & System)
Controls	Alphanumeric keypad permitting navigation, Reset, Mute, Silence, Resound, Evacuate, and 4 x programmable push buttons
Protocol	Apollo REACH
Number of Fire Zones	200 per individual panel, 2000 when networked
Number of Loops	1
Devices per Loop	Protocol dependent
Loop Current	500mA
On-Board Sounder Circuits	2 x 1 Amp programmable
On-Board Relays	2 x 1 Amp 30V AC/DC programmable (10mA, 5V min) - expandable to 4 using MXP-507
Auxiliary Supply	1 x 24V 500mA
Programmable Input	1 x monitored programmable input on-board
Programmable Key Switch Inputs	1 x volt-free input (standard enclosure), 8 x inputs (M, L, D enclosures)
Total Available Output Current	3A maximum available for loop current + sounder outputs + auxiliary supply
Mains Supply	200 - 240V 50-60 Hz AC (+10%, -15% tolerance) 1.0A Max
Charger Current	1A temperature compensated
Ethernet Port	10-Base-T, 100-Base-T - providing AdvancedLive connectivity (UK&I only)
Serial Port	1 x on-board RS232 connection for PC, modem, IP, or portable printer
USB Interface	1 x USB B type connection for PC communication
Programming	On-board keypad or PC running Windows tools
Event Log	5000 event & diagnostic + 500 fire
Networking	Optional plug-in network card (MXP-503 - standard, or MXP-509 - fault-tolerant)
Printer (Optional)	On-board (M, L, D enclosures only)
Enclosure / Colour	Steel IP30 / RAL7035
Metalwork Options	Flushing bezel, battery box, utility enclosure, termination enclosure, and rack mount
