FireCell Hardwired Network Card for Syncro AS Panel

The EMS FC-K555 is a hardwired network card designed to expand the capabilities of the FireCell Syncro AS system by allowing multiple control panels and repeaters to be connected via a secure, high-integrity network.

Using a simple 2-wire loop connection, up to 64 nodes can be linked, enabling event data to be shared across the network for coordinated system-wide control, indication, and response. Whether you're managing alarms, test modes, or disablements, the FC-K555 extends the powerful cause-and-effect programming of each Syncro panel across the entire network.

The system’s robust design ensures fault tolerance; in the event of a short or open circuit, communication continues uninterrupted. Even with multiple faults, the network intelligently isolates affected segments, allowing the remaining panels to operate autonomously.

Ideal for both new builds and retrofits, the FC-K555 supports open-ended network configurations and allows flexible setup via Loop Explorer software.

• Connects up to 64 panels or repeaters on a single network

• High-integrity, fault-tolerant protocol

• Secure against single open or short circuit faults

• 2-wire loop connection for ease of installation

• Supports open-ended networks — ideal for retrofits

• Shared network access for repeaters

• Enables network-wide test and disablement controls

• Network-wide cause-and-effect logic support

• Configurable response to network events per panel

• Programmed using Loop Explorer software
