The EMS FireCell FCX-170-001 is a wireless detector base designed to support and connect EMS FireCell detectors within a fully wireless fire alarm system.
It provides a secure mounting point and facilitates communication between the detector and the FireCell network using dual-band 868MHz radio.
Individually addressable via the fire control panel, the FCX-170-001 enables fast installation and simple system expansion with no need for wiring. It's ideal for use in retrofit applications, listed buildings, or environments where minimal disruption is key.
Compatible with FireCell optical, heat, and multi-sensor detectors, the base is EN54-25 compliant for radio communication in fire detection systems.
Wireless detector base for EMS FireCell detectors
Provides power and communication for mounted detectors
Uses dual-band 868MHz radio technology
Individually addressable at the fire panel
Fast, cable-free installation
Compatible with FireCell optical, heat, and multi-sensor heads
EN54-25 certified for wireless fire systems
Dimensions: | Ø:113mm x D:40mm (base only) |
Supply: Caution: Fitting of incorrect battery type invalidates the product certification & may result in poor performance | 6 x AA alkaline |
Operating frequency: | 868 MHz |
Output transmitter power: | Variable 0 to 14dBm (0 to 25mW) |
IP Rating: | IP23 |
Operating temperature: | -10°C to +55°C |
Storage temperature: | 5°C to 30°C |
Humidity: | 0 - 95% non-condensing |
Weight: | 0.45 kg (with detector) |
The EMS FireCell FCX-170-001 is a wireless detector base designed to support and connect EMS FireCell detectors within a fully wireless fire alarm system.
It provides a secure mounting point and facilitates communication between the detector and the FireCell network using dual-band 868MHz radio.
Individually addressable via the fire control panel, the FCX-170-001 enables fast installation and simple system expansion with no need for wiring. It's ideal for use in retrofit applications, listed buildings, or environments where minimal disruption is key.
Compatible with FireCell optical, heat, and multi-sensor detectors, the base is EN54-25 compliant for radio communication in fire detection systems.
Wireless detector base for EMS FireCell detectors
Provides power and communication for mounted detectors
Uses dual-band 868MHz radio technology
Individually addressable at the fire panel
Fast, cable-free installation
Compatible with FireCell optical, heat, and multi-sensor heads
EN54-25 certified for wireless fire systems
Dimensions: | Ø:113mm x D:40mm (base only) |
Supply: Caution: Fitting of incorrect battery type invalidates the product certification & may result in poor performance | 6 x AA alkaline |
Operating frequency: | 868 MHz |
Output transmitter power: | Variable 0 to 14dBm (0 to 25mW) |
IP Rating: | IP23 |
Operating temperature: | -10°C to +55°C |
Storage temperature: | 5°C to 30°C |
Humidity: | 0 - 95% non-condensing |
Weight: | 0.45 kg (with detector) |
