Vimpex ClamBell 24V 6" Red Fire Alarm Bell

The Vimpex ClamBell 24V is a robust fire alarm bell designed for professional installation within commercial fire alarm systems.

Manufactured for dependable performance and clear audible signalling, the ClamBell delivers a powerful 92–96 dB(A) output at 24V DC, ensuring effective alerting in a wide range of building types.

Available with shallow, deep, or purpose-designed weatherproof bases, the ClamBell provides flexible installation options to suit internal and external applications.

The weatherproof variant (CBE6-RW-024-EN) achieves IP56 (Cat. 2) protection when installed using the supplied glands, making it suitable for exposed outdoor environments.

Engineered for vertical mounting with clearly marked orientation arrows, the bell features grouped terminals supporting 0.5mm² to 2.5mm² cabling for straightforward wiring.

With low current consumption and wide operating voltage tolerance, the ClamBell is compatible with most 24V conventional fire alarm systems.

• 24V DC fire alarm bell for commercial systems

• 92–96 dB(A) sound output at 24V

• Low current consumption: 15mA maximum

• Voltage range: 20.4V – 27.6V DC

• Available base options:

  • Shallow Base (IP21C)

  • Deep Base (IP33C)

  • Weatherproof Base (IP56 Cat. 2)

• Four glanded cable entries on deep and weatherproof bases

• Suitable for 0.5mm² – 2.5mm² cables

• Operating temperature:

  • Shallow: -10°C to +50°C

  • Deep/Weatherproof: -25°C to +70°C

• Anti-tamper screw for added security

• Must be mounted vertically (orientation arrows up)
