The C-TEC BF370S “No Break” Surface Mount Call Point is a durable, resettable manual activation point designed for conventional fire alarm systems.
It is certified to EN54-11 (LPCB) and EN54-13 (BSI), delivering reliable performance in demanding environments.
Engineered with a smooth-action “No Break” element, the device mimics the feel of breaking glass while remaining clean and reusable.
Upon activation, a red LED ‘alarm ring’ illuminates the call point face for clear visual indication.
Its photoluminescent operating window stays visible for up to five minutes in low-light conditions.
The call point comes complete with a red back box, reset key, and “Not in Use” label, ready for surface mounting.
Certified to EN54-11 (LPCB) and EN54-13 (BSI)
Resettable element mimics the feel of breaking glass
Supplied with red back box, reset key, and “Not in Use” label
Red LED alarm ring provides clear visual indication on activation
Photoluminescent operating window visible for up to 5 minutes
Flush mounting requires the additional BF370SFP red flush plate
Specification | Detail |
---|---|
Voltage Range | 4.5 to 30 V DC |
Dimensions (W × H × D) | 87 × 88 × 62 mm (with back box) |
Construction | Red ABS plastic |
IP Rating | IP42 |
Supplied Resistors | 470 Ω and 680 Ω selectable via wiring |
Operating Temperature | −30 °C to +70 °C |
Certifications | EN54-11 (LPCB) and EN54-13 (BSI) |
The C-TEC BF370S “No Break” Surface Mount Call Point is a durable, resettable manual activation point designed for conventional fire alarm systems.
It is certified to EN54-11 (LPCB) and EN54-13 (BSI), delivering reliable performance in demanding environments.
Engineered with a smooth-action “No Break” element, the device mimics the feel of breaking glass while remaining clean and reusable.
Upon activation, a red LED ‘alarm ring’ illuminates the call point face for clear visual indication.
Its photoluminescent operating window stays visible for up to five minutes in low-light conditions.
The call point comes complete with a red back box, reset key, and “Not in Use” label, ready for surface mounting.
Certified to EN54-11 (LPCB) and EN54-13 (BSI)
Resettable element mimics the feel of breaking glass
Supplied with red back box, reset key, and “Not in Use” label
Red LED alarm ring provides clear visual indication on activation
Photoluminescent operating window visible for up to 5 minutes
Flush mounting requires the additional BF370SFP red flush plate
Specification | Detail |
---|---|
Voltage Range | 4.5 to 30 V DC |
Dimensions (W × H × D) | 87 × 88 × 62 mm (with back box) |
Construction | Red ABS plastic |
IP Rating | IP42 |
Supplied Resistors | 470 Ω and 680 Ω selectable via wiring |
Operating Temperature | −30 °C to +70 °C |
Certifications | EN54-11 (LPCB) and EN54-13 (BSI) |
