Eaton EXP-2R-MULTI Multi Function Radio Transceiver

The Eaton (Scantronic) EXP-2R-MULTI is a multi-function radio transceiver designed to expand the wireless capability of compatible intruder alarm systems.

It is a two-way radio device that enables communication between the control panel and wireless detectors, helping extend system coverage and improve signal performance where additional radio support is needed.

Designed for flexible system expansion, it can be used to improve wireless communication in larger properties or more complex installations where signal strength or range may otherwise be limited.

Using encrypted two-way wireless signalling, it helps provide reliable transmission between the panel and connected radio devices, supporting faster and more dependable system response.

The EXP-2R-MULTI is suited to residential and light commercial installations where additional radio support or extended wireless coverage is required as part of a wider intruder alarm system.

• Eaton (Scantronic) EXP-2R-MULTI multi-function radio transceiver

• Can operate as hybrid expander, standalone receiver or paired transceiver

• Four voltage-free relay outputs

• Monitored inputs for AC fail and low battery

• Loudspeaker output for external audio indication

• On-board sounder

• Tamper return input

• Local programming via LED display and menu keys

• AES128 encrypted two-way Secure Radio communication

• Built-in antenna with option for external antenna

• Supports up to 10 wireless devices in standalone mode

• Suitable for residential and commercial installations
