Eaton EXP-2R Two-Way Radio Expander

Name: Eaton EXP-2R Two-Way Radio Expander
Brand: Eaton
Availability: InStock

Code: FDS002/851

Call to place order

Code: FDS002/851

Eaton (Scantronic) EXP-2R two-way radio expander
Suitable for Grade 2 installations
Can provide radio HUA functionality in Grade 3 installations

Have a question about this? Click here

Overview Features Technical Data

The Eaton (Scantronic) EXP-2R is a two-way radio expander for compatible intruder alarm systems, designed to add wireless detection capability where extending hard wiring is not practical.

It is a bus-connected expander intended for Grade 2 installations, with support for radio hold-up alarm functionality in Grade 3 applications.

It uses encrypted two-way wireless communication to support reliable signalling between the alarm system and connected radio devices.

The Eaton EXP-2R Intruder Alarm Expander is suited to residential and light commercial installations where extra wireless zones are needed to extend system coverage.

The EXP-2R is a practical option for upgrades, extensions and retrofit work, helping installers expand a system without running additional cables throughout the building.

Eaton (Scantronic) EXP-2R two-way radio expander
Suitable for Grade 2 installations
Can provide radio HUA functionality in Grade 3 installations
Tri-channel swapping to help minimise signal interference
Device signal strengths indicated on the expander
Full diagnostics and fault reporting via the bus
Built-in piezo sounder for bus location
One button push for semi-auto addressing
LED diagnostics
AES128 encryption
Radio outputs can be used to trigger remote equipment
Compatible with Hold Up Devices and arming fobs for improved site coverage

Specification	Details
Product code	EXP-2R
Zones	10 or 30
EN 50131 compliance	Yes
Grade	PD6662:2017 Grade 2
Environmental class	2
RED compliance	Compliant
Power consumption	40mA
Radio frequency	868–868.5MHz (SSR mode), 868.6625MHz (Legacy mode)
Loudspeaker connection	Yes
Dimensions	230mm x 144mm x 44mm

Overview

Features

Technical Data

Specification	Details
Product code	EXP-2R
Zones	10 or 30
EN 50131 compliance	Yes
Grade	PD6662:2017 Grade 2
Environmental class	2
RED compliance	Compliant
Power consumption	40mA
Radio frequency	868–868.5MHz (SSR mode), 868.6625MHz (Legacy mode)
Loudspeaker connection	Yes
Dimensions	230mm x 144mm x 44mm
