C-TEC CA740 FastConvert 4-Way Addressable Zone Converter

The C-TEC CA740 FastConvert 4-Way Addressable Zone Converter is designed to facilitate the fast conversion and upgrade of a multi-zone conventional fire alarm system to an addressable C-TEC CAST system using pre-existing wiring. This innovative device by the well-renowned C-TEC can save fire alarm engineers thousands.

The C-TEC FastConvert is suitable for retrofit sites such as nursing homes and other facilities where conventional devices are being replaced in situ with addressable devices and the existing wiring needs to be retained.

This devices is fully compliant with the requirements of BS 5839-1.

No end-of-line devices, PSU or batteries required.

• Converts conventional zones to CAST addressable zones

• BS 5839-1

• Designed for retrofit fire alarm upgrades

• Retains existing zone wiring

• Supplied as a 4-zone converter

• Expandable to 8 zones using CA740PCB extender board

• Loop powered operation

• Onboard short-circuit loop isolator

• Four individual zone circuit isolators

• Supports up to 255 CAST devices per loop

• No PSU, batteries or end-of-line devices required
